4U Dual-Socket Server Implementation for
GPGPU and HPC Applications

Dual LGA2011 socket supports (2) E5-2600 series CPU
Intel® C602 PCH
(12+12) 240-pin DDR3 DIMM slots
Eight Full-Height/ Full-Length PCI-E Gen3 x16 slots support Eight Double-deck GPU adapters
Two Full-Height/ Full-Length PCI-E Gen3 x8 slots (one for mezzanie card)
Three Full-Height/ Full-Length PCI-E Gen2 x1 slots
One Full-Height/ Full-Length PCI slot
Six SATA-II connectors w/ RAID 0, 1, 10, 5 support
Two GbE (via Intel® I350-BT2), or (2) 10GbE (via Intel® X540-AT2) (-2T SKU)
Onboard BMC w/ IPMI and iKVM support
(2+1) Redundant, hot-swap RPSU high-efficiency 2,400W PSU , 80-PLUS Platinum

High density 4-socket systems supporting up to 1.5 TB of memory for enterprise-class database, virtualization, or HPC deployments
Intel® Server Board S4600LH2
Supports four Intel® Xeon® processor E5-4600 product family
Forty-eight memory sockets support LR/U/R-DIMMs delivers up to 1.5 TB of memory capacity
Four 3.5” hot-swap hard drives
Six PCIe Gen 3 x16 Super Slots and two Intel® I/O Expansion Module PCIe x8 Gen 3
Intel® Remote Management Module 4 included
Integrated Dual Port Intel® Ethernet Controller I350 (1 GbE)
Eleven hot-swappable redundant fans
Two 1600W AC Platinum efficiency common redundant power supplies
