Supermicro X10DRC-LN4+ Motherboard

SKU: MBD-X10DRC-LN4+

Featured Product Image

Key Features:

  • Dual socket R3 (LGA 2011) supports Intel® Xeon® processor  E5-2600 v4/ v3 family; UPI up to 9.6GT/s
  • Intel® C612 chipset
  • Up to 3TB ECC 3DS LRDIMM, up to DDR4-2400MHz;
    24x DIMM slots
  • 2 PCI-E 3.0 x16, 3 PCI-E 3.0 x8, and 1 PCI-E 2.0 x4 (in x8) slot
  • Quad LAN w/ Intel® i350 GbE
  • 10 SATA3 (6Gbps) ports w/ Intel® C612 controller; RAID 0, 1, 5, 10
  • 8 SAS3 (12Gbps) ports w/ Broadcom® 3108 controller; RAID 0, 1, 5, 6, 10, 50, 60
    SuperCap option support
  • Integrated IPMI 2.0 and KVM with Dedicated LAN
  • 5 USB 3.0 (2 rear, 2 front panel, 1 Type-A)
    4 USB 2.0 (2 rear, 2 front panel)
  • 30-Day Warranty
  • Condition: Open Box - New
Request a Quote

$949.00

Share this product:

Description

Supermicro X10DRC-LN4+ Motherboard

Product

Manufacturer Part # MBD-X10DRC-LN4+
Manufacture Date 2020

Physical Stats

Form Factor E.E. ATX
Dimensions 13.68" x 13" (34.75cm x 33.02cm)

Processor/Cache



CPU Intel® Xeon® processor E5-2600 v3, Intel® Xeon® processor E5-2600 v4.
Dual Socket R3 (LGA 2011) supported, CPU TDP support Up to 145W
Cores / Cache Up to 22 cores / Up to 55MB cache
QPI
 1 QPI up to 9.6GT/s

System Memory

Memory Capacity Up to 768GB Registered ECC RDIMM, DDR4-2400MHz; Up to 3TB 3DS ECC LRDIMM, in 24 DIMM slots
Memory Type 2400/2133/1866/1600MHz ECC DDR4 SDRAM 72-bit
DIMM Sizes
 RDIMM: 4GB, 8GB, 16GB, 32GB
LRDIMM: 32GB, 64GB
3DS LRDIMM: 128GB
Memory Voltage 1.2V
Error Detection Corrects single-bit errors

On-Board Devices

Chipset Intel® C612
SATA Intel® C612 controller for 10 SATA3 (6 Gbps) ports; RAID 0,1,5,10
IPMI Support for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
ASPEED AST2400 BMC
AHCI SATA SATA3 (6Gbps); RAID 0, 1, 5, 10
SCU SATA SATA3 (6Gbps); RAID 0, 1, 5, 10
Network Controllers Quad LAN with Intel® i350 Gigabit Ethernet Controller
Single LAN with Virtual Machine Device Queues reduce I/O overhead
Single LAN with Supports 10Base-T, 100BASE-TX, and 1000BASE-T, RJ45 output
Single LAN with 1 Realtek RTL8211E PHY (dedicated IPMI)
Graphics
 Aspeed AST2400 BMC

Input / Output

SATA 10 SATA3 (6Gbps) port
LAN 4 RJ45 Gigabit Ethernet LAN ports
1 RJ45 Dedicated IPMI LAN port
USB 2 USB 2.0 ports (2 rear Type A)
3 USB 3.0 ports (2 rear + 1 Type A)
VGA 1 VGA port
Serial Port / Header 2 COM Ports (1 rear, 1 header)
2 fast UART 16550 serial
TPM 1 TPM Header

Expansion Slots

PCI-Express 2 PCI-E 3.0 x16,
3 PCI-E 3.0 x8
1 PCI-E 2.0 x4 (in x8 slot)

System BIOS

BIOS Type
 128Mb SPI Flash EEPROM with AMI BIOS
BIOS Features Plug and Play (PnP)
PCI 2.3
ACPI 1.0 / 2.0 / 3.0 / 4.0
USB Keyboard support
SMBIOS 2.7.1
UEFI 2.3.1

Management

 Software Intel® Node Manager, IPMI2.0, KVM with dedicated LAN, NMI, SuperDoctor® 5, Watchdog
Power Configurations ACPI Power Management
Power-on mode for AC power recovery
